Bài 6: Multi-PSP Integration - VNPay, MoMo, ZaloPay, Stripe

Kiến trúc FinTech & Payment Platform

Phần 2: Core Payment Engine

xdev.asia

Giới thiệu

Một payment platform thực tế luôn cần tích hợp nhiều PSP (Payment Service Provider) để tối ưu success rate, chi phí, và coverage. Bài này hướng dẫn thiết kế abstraction layer cho multi-PSP integration với smart routing.

---

1. PSP Abstraction Layer

1.1 Adapter Pattern

┌────────────────────────────────────────────────────┐
│                 PAYMENT SERVICE                     │
│                                                     │
│  ┌──────────────────────────────────────────────┐  │
│  │            PSP Interface (Port)               │  │
│  │  authorize() / capture() / refund() / void() │  │
│  └──────────────────┬───────────────────────────┘  │
│                     │                               │
│      ┌──────────────┼──────────────┐               │
│      │              │              │               │
│  ┌───▼────┐   ┌─────▼────┐  ┌─────▼────┐         │
│  │ VNPay  │   │  MoMo    │  │ Stripe   │  ...    │
│  │Adapter │   │ Adapter  │  │ Adapter  │         │
│  └───┬────┘   └─────┬────┘  └─────┬────┘         │
└──────┼──────────────┼─────────────┼────────────────┘
       │              │             │
   ┌───▼────┐   ┌─────▼────┐  ┌────▼─────┐
   │ VNPay  │   │  MoMo    │  │ Stripe   │
   │  API   │   │   API    │  │   API    │
   └────────┘   └──────────┘  └──────────┘

1.2 PSP Interface

public interface PaymentServiceProvider {
    String getId();
    Set<PaymentMethod> supportedMethods();
    Set<Currency> supportedCurrencies();

    AuthResult authorize(AuthRequest request);
    CaptureResult capture(CaptureRequest request);
    RefundResult refund(RefundRequest request);
    VoidResult voidPayment(VoidRequest request);
    PaymentStatus queryStatus(String pspReference);
}

1.3 VNPay Adapter

@Component
public class VNPayAdapter implements PaymentServiceProvider {

    @Override
    public String getId() { return "vnpay"; }

    @Override
    public Set<PaymentMethod> supportedMethods() {
        return Set.of(
            PaymentMethod.ATM_CARD,
            PaymentMethod.CREDIT_CARD,
            PaymentMethod.QR_CODE,
            PaymentMethod.BANK_TRANSFER
        );
    }

    @Override
    public AuthResult authorize(AuthRequest request) {
        // Build VNPay-specific parameters
        var params = new TreeMap<String, String>();
        params.put("vnp_Version", "2.1.0");
        params.put("vnp_Command", "pay");
        params.put("vnp_TmnCode", config.getTmnCode());
        params.put("vnp_Amount", String.valueOf(
            request.getAmount().multiply(100).longValue()));
        params.put("vnp_CurrCode", "VND");
        params.put("vnp_TxnRef", request.getOrderId());
        params.put("vnp_OrderInfo", request.getDescription());
        params.put("vnp_ReturnUrl", config.getReturnUrl());

        // Sign with HMAC-SHA512
        String signature = HmacUtils.hmacSha512(
            config.getHashSecret(), buildQueryString(params));
        params.put("vnp_SecureHash", signature);

        // Return redirect URL for customer
        String paymentUrl = config.getPayUrl() + "?" + buildQueryString(params);
        return AuthResult.redirect(paymentUrl);
    }
}

---

2. Smart Routing

2.1 Routing Engine

@Service
public class PSPRouter {
    private final List<RoutingRule> rules;
    private final PSPHealthMonitor healthMonitor;

    public PaymentServiceProvider selectPSP(PaymentRequest request) {
        // 1. Filter by capability
        var candidates = pspRegistry.getAll().stream()
            .filter(psp -> psp.supportedMethods().contains(request.getMethod()))
            .filter(psp -> psp.supportedCurrencies().contains(request.getCurrency()))
            .filter(psp -> healthMonitor.isHealthy(psp.getId()))
            .toList();

        // 2. Apply routing rules
        for (var rule : rules) {
            var result = rule.evaluate(request, candidates);
            if (result.isPresent()) return result.get();
        }

        // 3. Default: cost-optimized selection
        return candidates.stream()
            .min(Comparator.comparing(psp -> getFeeRate(psp, request)))
            .orElseThrow(() -> new NoPSPAvailableException());
    }
}

2.2 Routing Strategies

Strategy	Logic	Use Case
Cost-optimized	Lowest fee PSP	Default
Success-rate	Highest success rate PSP	High-value transactions
Latency-optimized	Fastest PSP	Real-time payments
Geographic	PSP nearest to customer	Cross-border
Load-balanced	Round-robin/weighted	Traffic distribution
A/B testing	Random split	Testing new PSP

2.3 Failover Pattern

Primary PSP (VNPay)
    │
    ├── Success → Done
    │
    ├── Timeout/5xx → Retry once
    │       │
    │       ├── Success → Done
    │       │
    │       └── Fail → Fallback PSP (Stripe)
    │                   │
    │                   ├── Success → Done
    │                   │
    │                   └── Fail → Return error to customer
    │
    └── Terminal error (declined) → Return error (no fallback)

---

3. PSP Health Monitoring

@Component
public class PSPHealthMonitor {
    // Track success rate per PSP with sliding window
    private final Map<String, SlidingWindowCounter> successRates;

    @Scheduled(fixedRate = 60000) // Every minute
    public void checkHealth() {
        for (var entry : successRates.entrySet()) {
            var pspId = entry.getKey();
            var counter = entry.getValue();
            double rate = counter.getSuccessRate();

            if (rate < 0.5) { // < 50% success rate
                circuitBreaker.open(pspId);
                alertService.send("PSP " + pspId + " degraded: " + rate);
            }
        }
    }

    public boolean isHealthy(String pspId) {
        return !circuitBreaker.isOpen(pspId);
    }
}

---

4. Webhook Handling

4.1 Receiving PSP Callbacks

@RestController
@RequestMapping("/webhooks")
public class WebhookController {

    @PostMapping("/vnpay")
    public ResponseEntity<String> handleVNPayCallback(
            @RequestParam Map<String, String> params) {
        // 1. Verify signature
        if (!vnpayAdapter.verifySignature(params)) {
            return ResponseEntity.badRequest().body("Invalid signature");
        }

        // 2. Process callback
        var paymentId = params.get("vnp_TxnRef");
        var responseCode = params.get("vnp_ResponseCode");

        webhookProcessor.process(WebhookEvent.builder()
            .pspId("vnpay")
            .paymentId(paymentId)
            .status(mapStatus(responseCode))
            .rawPayload(params)
            .build());

        return ResponseEntity.ok("OK");
    }

    @PostMapping("/stripe")
    public ResponseEntity<Void> handleStripeWebhook(
            @RequestBody String payload,
            @RequestHeader("Stripe-Signature") String signature) {
        // Verify Stripe webhook signature
        var event = stripeAdapter.verifyAndParse(payload, signature);
        webhookProcessor.process(event);
        return ResponseEntity.ok().build();
    }
}

---

Tổng kết

Multi-PSP integration cần:

• Adapter Pattern để abstract away PSP-specific APIs
• Smart Routing để tối ưu cost, success rate, latency
• Failover tự động khi PSP gặp sự cố
• Health Monitoring với circuit breaker
• Webhook handling cho mỗi PSP với signature verification

Bài tiếp theo: Reconciliation & Settlement Engine — hệ thống đối soát và quy trình settlement tự động.
