Bài 22: GitOps với ArgoCD

Cloud Native Microservices Architecture

Phần 7: CI/CD & Deployment Strategies

xdev.asia

Giới thiệu

Trong CI/CD truyền thống, script deploy chạy kubectl apply trực tiếp lên cluster. Ai đang chạy gì? Cluster hiện tại ở trạng thái nào? Làm sao rollback?

GitOps đảo ngược mô hình này: Git là source of truth cho trạng thái cluster. Operator (ArgoCD) liên tục sync cluster về đúng trạng thái khai báo trong Git.

---

1. GitOps Principles

1.1 Core Principles

1. DECLARATIVE
   Toàn bộ trạng thái hệ thống được khai báo trong Git
   (YAML manifests, Helm values, Kustomize overlays)

2. VERSIONED & IMMUTABLE
   Git history = audit log đầy đủ của mọi thay đổi
   "Ai thay đổi gì, lúc nào, tại sao" (commit message, PR)

3. PULLED AUTOMATICALLY
   Agent (ArgoCD/Flux) pull từ Git và apply
   Không có CI push thẳng vào cluster (không cần cluster credentials trong CI)

4. CONTINUOUSLY RECONCILED
   Agent liên tục compare desired state (Git) với actual state (cluster)
   Tự động "heal" nếu ai đó thay đổi trực tiếp trên cluster

1.2 Tại sao GitOps tốt hơn "kubectl apply trong CI"?

	Traditional CI Push	GitOps (ArgoCD)
Credentials	CI cần cluster credentials	Chỉ ArgoCD cần, CI không có
Audit trail	CI logs (dễ mất)	Git history (permanent)
Rollback	Re-run CI với old version	git revert → auto deploy
Drift detection	Không	Tự động detect và fix
Multi-cluster	Phức tạp	ApplicationSet handles it
Review process	Ad-hoc scripts	Pull Request workflow

---

2. ArgoCD Architecture

┌─────────────────────────────────────────────────────────────────┐
│                        ArgoCD                                   │
│                                                                 │
│  ┌──────────────┐  ┌──────────────┐  ┌───────────────────────┐ │
│  │  API Server  │  │  Repo Server │  │  Application          │ │
│  │  (REST+gRPC) │  │  (Git clone, │  │  Controller           │ │
│  │  CLI/UI/CD   │  │   render     │  │  (reconcile loop)     │ │
│  └──────┬───────┘  │   manifests) │  └──────────┬────────────┘ │
│         │          └──────────────┘             │              │
│  ┌──────▼─────────────────────────────────────┐ │              │
│  │              Redis Cache                   │ │              │
│  └─────────────────────────────────────────────┘ │              │
└──────────────────────────────────────────────────┼──────────────┘
                                                   │
                                    ┌──────────────▼──────┐
                        Pull │      │    Kubernetes       │
                        from │      │    Cluster          │
                        Git  │      └─────────────────────┘
                             ▼
                    ┌──────────────────┐
                    │  Git Repository  │
                    │  (k8s-manifests) │
                    └──────────────────┘

Repo Server: Clone Git repo, render manifests (Helm/Kustomize/plain YAML)

Application Controller: So sánh desired state (Git) với live state (Cluster), tạo sync actions

API Server: REST API cho UI, CLI, CI/CD webhooks

---

3. Cài đặt ArgoCD

kubectl create namespace argocd

kubectl apply -n argocd \
  -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml

# Lấy initial admin password
kubectl -n argocd get secret argocd-initial-admin-secret \
  -o jsonpath="{.data.password}" | base64 -d

# Port-forward UI
kubectl port-forward svc/argocd-server -n argocd 8080:443

# Cài ArgoCD CLI
brew install argocd
argocd login localhost:8080

---

4. Application Manifest

4.1 Application CRD

# order-service-app.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: order-service-prod
  namespace: argocd
  # Đừng xóa khi app bị xóa (cascade protection)
  finalizers:
    - resources-finalizer.argocd.argoproj.io
spec:
  project: backend-services

  source:
    repoURL: https://github.com/myorg/k8s-manifests.git
    targetRevision: main
    # Thư mục trong repo
    path: services/order-service/overlays/production

  destination:
    server: https://kubernetes.default.svc
    namespace: services-prod

  syncPolicy:
    # Tự động sync khi Git thay đổi
    automated:
      prune: true       # Xóa resources không còn trong Git
      selfHeal: true    # Tự fix nếu ai kubectl edit trực tiếp
      allowEmpty: false # Không sync nếu manifest rỗng (safety)

    syncOptions:
      - CreateNamespace=true
      - PrunePropagationPolicy=foreground
      - RespectIgnoreDifferences=true

    # Retry nếu sync fail
    retry:
      limit: 5
      backoff:
        duration: 5s
        factor: 2
        maxDuration: 3m

  # Bỏ qua một số fields khi so sánh (thường do auto-scaling thay đổi)
  ignoreDifferences:
    - group: apps
      kind: Deployment
      jsonPointers:
        - /spec/replicas   # HPA manage replicas, bỏ qua drift này

4.2 ArgoCD Project — quản lý permissions

apiVersion: argoproj.io/v1alpha1
kind: AppProject
metadata:
  name: backend-services
  namespace: argocd
spec:
  description: "Backend microservices"

  # Chỉ cho phép source từ các repos này
  sourceRepos:
    - 'https://github.com/myorg/k8s-manifests.git'

  # Chỉ deploy vào namespace này
  destinations:
    - namespace: services-prod
      server: https://kubernetes.default.svc
    - namespace: services-staging
      server: https://kubernetes.default.svc

  # Chỉ allow các resource kinds này
  clusterResourceWhitelist:
    - group: ''
      kind: Namespace

  namespaceResourceWhitelist:
    - group: 'apps'
      kind: Deployment
    - group: ''
      kind: Service
    - group: autoscaling
      kind: HorizontalPodAutoscaler
    # Không cho phép ClusterRole, CRD, etc.

  roles:
    - name: developer
      description: Deploy access for developers
      policies:
        - p, proj:backend-services:developer, applications, sync, backend-services/*, allow
        - p, proj:backend-services:developer, applications, get, backend-services/*, allow
      groups:
        - github:myorg:backend-team

---

5. Kustomize — Multi-environment Configuration

5.1 Directory structure

k8s-manifests/
services/
  order-service/
    base/                          ← Shared manifests
      deployment.yaml
      service.yaml
      hpa.yaml
      kustomization.yaml
    overlays/
      staging/                     ← Staging overrides
        kustomization.yaml
        replica-patch.yaml
        env-patch.yaml
      production/                  ← Production overrides
        kustomization.yaml
        replica-patch.yaml
        env-patch.yaml
        resource-limits-patch.yaml

5.2 Base manifests

# base/kustomization.yaml
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization

resources:
  - deployment.yaml
  - service.yaml
  - hpa.yaml

commonLabels:
  app: order-service
  managed-by: argocd

# base/deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: order-service
spec:
  replicas: 1     ← Base, override per environment
  template:
    spec:
      containers:
        - name: order-service
          image: registry.example.com/order-service:latest   ← CI sẽ update tag này
          resources:
            requests:
              cpu: "250m"
              memory: "512Mi"
            limits:
              cpu: "500m"
              memory: "1Gi"

5.3 Staging overlay

# overlays/staging/kustomization.yaml
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization

namePrefix: staging-
namespace: services-staging

bases:
  - ../../base

patches:
  - path: replica-patch.yaml
  - path: env-patch.yaml

images:
  - name: registry.example.com/order-service
    newTag: sha-abc1234   ← CI cập nhật field này

# overlays/staging/replica-patch.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: order-service
spec:
  replicas: 2

# overlays/staging/env-patch.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: order-service
spec:
  template:
    spec:
      containers:
        - name: order-service
          env:
            - name: ENVIRONMENT
              value: staging
            - name: LOG_LEVEL
              value: DEBUG
            - name: DB_HOST
              valueFrom:
                secretKeyRef:
                  name: order-db-staging
                  key: host

5.4 Production overlay

# overlays/production/kustomization.yaml
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization

namespace: services-prod

bases:
  - ../../base

patches:
  - path: replica-patch.yaml
  - path: resource-limits-patch.yaml
  - path: env-patch.yaml

images:
  - name: registry.example.com/order-service
    newTag: 1.2.3   ← Semantic version cho production

# overlays/production/replica-patch.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: order-service
spec:
  replicas: 5   ← Production needs more replicas

---

6. CI Update Image Tag (GitOps Flow)

# Trong CI pipeline (GitHub Actions)
- name: Update image tag in GitOps repo
  run: |
    # Clone manifest repo
    git clone https://x-access-token:${{ secrets.GITOPS_TOKEN }}@github.com/myorg/k8s-manifests.git
    cd k8s-manifests

    # Update image tag cho staging
    cd services/order-service/overlays/staging
    kustomize edit set image registry.example.com/order-service:sha-${{ github.sha }}

    # Commit và push
    git config user.email "[email protected]"
    git config user.name "CI Bot"
    git add .
    git commit -m "chore(order-service): deploy sha-${{ github.sha }} to staging

    Triggered by: https://github.com/${{ github.repository }}/actions/runs/${{ github.run_id }}"
    git push

    # ArgoCD sẽ auto-detect và deploy

Promote to Production (manual step):

- name: Promote to production (manual approval required)
  environment: production   # GitHub Environment với required reviewers
  run: |
    cd k8s-manifests/services/order-service/overlays/production
    kustomize edit set image registry.example.com/order-service:${{ needs.build.outputs.version }}
    git add . && git commit -m "chore: promote order-service ${{ needs.build.outputs.version }} to prod"
    git push

---

7. ApplicationSet — Multi-cluster, Multi-tenant

# Tự động tạo Application cho mỗi cluster/env combination
apiVersion: argoproj.io/v1alpha1
kind: ApplicationSet
metadata:
  name: order-service
  namespace: argocd
spec:
  generators:
    - matrix:
        generators:
          - list:
              elements:
                - cluster: staging
                  url: https://staging-cluster:6443
                  namespace: services-staging
                - cluster: prod-us
                  url: https://prod-us-cluster:6443
                  namespace: services-prod
                - cluster: prod-eu
                  url: https://prod-eu-cluster:6443
                  namespace: services-prod
          - list:
              elements:
                - service: order-service
                - service: payment-service
                - service: inventory-service

  template:
    metadata:
      name: '{{service}}-{{cluster}}'
    spec:
      project: backend-services
      source:
        repoURL: https://github.com/myorg/k8s-manifests.git
        targetRevision: main
        path: 'services/{{service}}/overlays/{{cluster}}'
      destination:
        server: '{{url}}'
        namespace: '{{namespace}}'
      syncPolicy:
        automated:
          prune: true
          selfHeal: true

---

8. Rollback

GitOps làm rollback trực quan:

# Option 1: git revert (recommended — tạo revert commit, không rewrite history)
git revert abc1234 --no-edit
git push
# ArgoCD auto-deploys revert commit

# Option 2: ArgoCD UI — click "History and Rollback" → chọn revision cũ → sync

# Option 3: ArgoCD CLI
argocd app history order-service-prod
argocd app rollback order-service-prod 5  # Rollback về revision 5

---

Tóm tắt

Khái niệm	Mục đích
GitOps	Git = source of truth cho cluster state
ArgoCD Application	Khai báo "app X = code từ Git path Y, deploy vào namespace Z"
automated sync	ArgoCD tự sync mỗi khi Git thay đổi
selfHeal	Tự động revert manual changes trên cluster
Kustomize overlays	Customize manifest per environment mà không duplicate
ApplicationSet	Deploy cùng app lên nhiều cluster/environment
Git revert = rollback	Rollback an toàn, có audit trail

Bài tiếp theo: Deployment Strategies — Canary, Blue/Green & Progressive Delivery
