Bài 8: MFA, Passkeys & Emergency Access cho Nhân viên Y tế

Xây dựng Hệ thống Y tế Microservices — Quarkus, PostgreSQL, Keycloak chuẩn HIPAA

Phần 2: Identity & Access Management với Keycloak

xdev.asia

1. MFA Strategy cho Môi trường Y Tế

1.1. Thách thức MFA trong Bệnh viện

Bệnh viện có môi trường vận hành đặc biệt so với doanh nghiệp thông thường:

Thách thức	Mô tả	Giải pháp
Shared workstations	Nhiều bác sĩ/y tá dùng chung máy tính	Fast switching, tap-and-go
Thời gian phản hồi	Cấp cứu cần truy cập trong giây	Conditional MFA, proximity badge
Găng tay y tế	Không thể dùng fingerprint	WebAuthn security key, PIN
Nhiều lần đăng nhập/ngày	Bác sĩ đăng nhập 30-50 lần/ngày	SSO + short MFA memory
Thiết bị cá nhân hạn chế	Không phải ai cũng có smartphone	Hardware token option

1.2. MFA Factor Matrix

User Type	Primary	Secondary	Fallback
Doctor	Passkey / WebAuthn	TOTP App	Recovery codes
Nurse	Proximity Badge	PIN (6 digits)	TOTP App
Lab Tech	TOTP App	Security Key	Recovery codes
Admin	Security Key	TOTP App	Admin recovery procedure
Patient Portal	SMS OTP	Email OTP	Support call

2. Keycloak Authentication Flow cho Y Tế

2.1. Conditional Authentication Flow

{
  "alias": "healthcare-browser-flow",
  "description": "Healthcare-specific authentication flow with conditional MFA",
  "providerId": "basic-flow",
  "topLevel": true,
  "builtIn": false,
  "authenticationExecutions": [
    {
      "authenticator": "auth-cookie",
      "requirement": "ALTERNATIVE",
      "priority": 10
    },
    {
      "authenticator": "identity-provider-redirector",
      "requirement": "ALTERNATIVE",
      "priority": 20
    },
    {
      "flowAlias": "healthcare-forms",
      "requirement": "ALTERNATIVE",
      "priority": 30
    }
  ]
}

2.2. Healthcare Forms Sub-flow

healthcare-forms (ALTERNATIVE)
├── Username/Password Form (REQUIRED)
│
├── healthcare-mfa-conditional (CONDITIONAL)
│   ├── Condition: User Role = "patient"
│   │   → SMS OTP Authenticator (REQUIRED)
│   │
│   ├── Condition: IP NOT in 10.0.0.0/8 (external access)
│   │   → WebAuthn Authenticator (REQUIRED)
│   │
│   ├── Condition: User has configured WebAuthn
│   │   → WebAuthn Passwordless (ALTERNATIVE)
│   │
│   └── Condition: Default (internal network)
│       → OTP Form (CONDITIONAL - only if configured)
│
└── healthcare-session-note (REQUIRED)
    → Set session attributes (department, hospital)

2.3. Keycloak Conditional OTP Configuration

{
  "alias": "conditional-mfa-healthcare",
  "description": "MFA required for external access, optional for internal",
  "authenticationExecutions": [
    {
      "authenticator": "conditional-user-configured",
      "requirement": "REQUIRED",
      "priority": 10
    },
    {
      "authenticator": "auth-conditional-otp-form",
      "requirement": "REQUIRED",
      "priority": 20,
      "authenticatorConfig": {
        "alias": "healthcare-otp-config",
        "config": {
          "forceOtpRole": "require_mfa",
          "skipOtpRole": "skip_internal_mfa",
          "noOtpRequiredForHeaderPattern": "",
          "otpControlAttribute": "mfa_required",
          "defaultOtpOutcome": "force"
        }
      }
    }
  ]
}

3. WebAuthn / Passkeys cho Y Tế

3.1. Keycloak WebAuthn Configuration

{
  "webAuthnPolicyRpEntityName": "Healthcare Platform",
  "webAuthnPolicyRpId": "hospital.vn",
  "webAuthnPolicySignatureAlgorithms": ["ES256", "RS256"],
  "webAuthnPolicyAttestationConveyancePreference": "direct",
  "webAuthnPolicyAuthenticatorAttachment": "cross-platform",
  "webAuthnPolicyRequireResidentKey": "Yes",
  "webAuthnPolicyUserVerificationRequirement": "preferred",
  "webAuthnPolicyCreateTimeout": 60,
  "webAuthnPolicyAvoidSameAuthenticatorRegister": true,

  "webAuthnPolicyPasswordlessRpEntityName": "Healthcare Platform",
  "webAuthnPolicyPasswordlessRpId": "hospital.vn",
  "webAuthnPolicyPasswordlessSignatureAlgorithms": ["ES256"],
  "webAuthnPolicyPasswordlessAuthenticatorAttachment": "platform",
  "webAuthnPolicyPasswordlessRequireResidentKey": "Yes",
  "webAuthnPolicyPasswordlessUserVerificationRequirement": "required"
}

3.2. Supported Authenticators cho Bệnh viện

┌─────────────────────────────────────────────────────┐
│           Recommended Security Keys                  │
├─────────────────────┬───────────────────────────────┤
│ YubiKey 5 NFC       │ • USB-A/C + NFC              │
│                     │ • FIDO2/WebAuthn + TOTP       │
│                     │ • Ideal for doctors (mobile)  │
├─────────────────────┼───────────────────────────────┤
│ YubiKey 5C Nano     │ • Ultra-compact USB-C         │
│                     │ • Leave in workstation         │
│                     │ • Ideal for nurse stations    │
├─────────────────────┼───────────────────────────────┤
│ Feitian BioPass     │ • Built-in fingerprint        │
│                     │ • USB-A                        │
│                     │ • Ideal for admin              │
├─────────────────────┼───────────────────────────────┤
│ Platform Passkeys   │ • Windows Hello / Touch ID     │
│                     │ • No hardware needed           │
│                     │ • Ideal for personal devices   │
└─────────────────────┴───────────────────────────────┘

4. Session Management cho Shared Workstations

4.1. Fast Session Switching

// Quarkus endpoint for fast user switching
@Path("/api/v1/session")
public class SessionResource {

    @Inject
    SecurityIdentity identity;

    @POST
    @Path("/switch")
    @PermitAll
    public Response switchUser(@HeaderParam("X-Smart-Card-ID") String smartCardId) {
        // Validate smart card / proximity badge
        if (smartCardId == null || smartCardId.isEmpty()) {
            return Response.status(400)
                .entity(Map.of("error", "Smart card ID required"))
                .build();
        }

        // Redirect to Keycloak with kc_idp_hint for smart card IDP
        URI redirectUri = UriBuilder
            .fromUri("https://keycloak.hospital.vn/realms/healthcare/protocol/openid-connect/auth")
            .queryParam("client_id", "his-web-app")
            .queryParam("response_type", "code")
            .queryParam("scope", "openid")
            .queryParam("kc_idp_hint", "smart-card")
            .queryParam("login_hint", smartCardId)
            .queryParam("prompt", "login")  // Force re-auth
            .build();

        return Response.temporaryRedirect(redirectUri).build();
    }

    @POST
    @Path("/lock")
    @Authenticated
    public Response lockSession() {
        // Lock current session (require re-auth on next access)
        // Audit log: session locked
        auditService.log("SESSION_LOCK", identity.getPrincipal().getName());

        return Response.ok(Map.of(
            "status", "locked",
            "message", "Session locked. Re-authentication required."
        )).build();
    }
}

4.2. Auto-Logoff Configuration

# application.properties - Session timeouts for healthcare
# Clinical workstations: short idle timeout
quarkus.oidc.token.age=300
quarkus.oidc.token.refresh-token-time-skew=30

# Force re-authentication for sensitive operations
quarkus.oidc.authentication.session-age-extension=0

# Session cookie settings
quarkus.http.auth.session.cookie-name=__Host-healthcare_session
quarkus.http.auth.session.cookie-secure=true
quarkus.http.auth.session.cookie-http-only=true
quarkus.http.auth.session.cookie-same-site=Strict

5. Proximity Badge Authentication

5.1. Architecture

┌──────────┐    BLE/NFC    ┌──────────────┐    HTTPS    ┌──────────┐
│ Badge    │ ────────────▶ │  Badge       │ ──────────▶ │ Keycloak │
│ Reader   │               │  Auth Service│              │          │
└──────────┘               └──────────────┘              └──────────┘
                                  │
                           ┌──────▼──────┐
                           │ Map badge   │
                           │ ID to user  │
                           │ account     │
                           └──────┬──────┘
                                  │
                           ┌──────▼──────┐
                           │ Issue       │
                           │ auth token  │
                           │ (time-      │
                           │ limited)    │
                           └─────────────┘

5.2. Badge Authentication SPI

// Custom Keycloak Authenticator SPI for proximity badge
public class BadgeAuthenticator implements Authenticator {

    @Override
    public void authenticate(AuthenticationFlowContext context) {
        String badgeId = context.getHttpRequest()
            .getHttpHeaders()
            .getHeaderString("X-Badge-ID");

        if (badgeId == null) {
            // Show badge scan prompt
            context.challenge(
                context.form()
                    .setAttribute("realm", context.getRealm())
                    .createForm("badge-scan.ftl")
            );
            return;
        }

        // Look up user by badge ID attribute
        UserModel user = context.getSession().users()
            .searchForUserByUserAttributeStream(
                context.getRealm(), "badgeId", badgeId)
            .findFirst()
            .orElse(null);

        if (user == null) {
            context.failureChallenge(
                AuthenticationFlowError.INVALID_CREDENTIALS,
                context.form().setError("Badge not recognized")
                    .createForm("badge-scan.ftl")
            );
            return;
        }

        // Badge alone is first factor — require PIN as second factor
        context.setUser(user);
        context.success();
    }

    @Override
    public void action(AuthenticationFlowContext context) {
        // Handle badge ID from form submission
        MultivaluedMap<String, String> formData =
            context.getHttpRequest().getDecodedFormParameters();
        String badgeId = formData.getFirst("badgeId");

        if (badgeId != null) {
            context.getHttpRequest().getHttpHeaders()
                .getRequestHeaders().putSingle("X-Badge-ID", badgeId);
            authenticate(context);
        }
    }

    @Override
    public boolean requiresUser() { return false; }

    @Override
    public boolean configuredFor(KeycloakSession session,
            RealmModel realm, UserModel user) { return true; }
}

6. Recovery Procedures

6.1. Account Recovery flow cho Y Tế

Scenario 1: Bác sĩ quên password + mất phone (TOTP)
─────────────────────────────────────────────────────
1. Bác sĩ contact IT Help Desk (phone + employee ID verify)
2. Help Desk officer verifies identity (employee ID, department, manager confirm)
3. Help Desk issues temporary password via sealed envelope / secure channel
4. Doctor logs in → forced password change + MFA re-enrollment
5. Audit: recovery event logged, previous MFA devices revoked

Scenario 2: Emergency access khi Keycloak down
────────────────────────────────────────────────
1. Activate emergency access mode (requires 2 admin approvals)
2. Local authentication fallback (pre-provisioned local accounts)
3. All actions logged to local file → synced when Keycloak recovers
4. Emergency period limited to 4 hours
5. Post-incident: full audit review required

7. Tổng kết

Trong bài học này, chúng ta đã:

• Phân tích thách thức MFA đặc thù trong môi trường bệnh viện
• Thiết kế MFA strategy phù hợp cho từng loại nhân viên y tế
• Cấu hình Conditional Authentication Flow trong Keycloak (skip MFA trên mạng nội bộ)
• Triển khai WebAuthn/Passkeys cho clinical workstations
• Xây dựng Fast Session Switching cho shared workstations
• Implement Proximity Badge Authentication SPI
• Thiết kế Recovery Procedures cho y tế

Bài tập

1. Cấu hình Keycloak authentication flow với conditional MFA (internal vs external network)
2. Register WebAuthn security key và test passkey login
3. Implement auto-logoff sau 10 phút idle cho clinical workstations
4. Viết documentation cho Emergency Access procedure

---

---
